| Item |
Parameter |
| Battery System |
Battery Type |
LiFePO4 Battery Cell |
| Configration Of Battery Cluster |
12P216S |
| Rated Voltage Of Battery System(V) |
691.2 |
| Battery Capacity(kWh) |
1708.6 |
| Voltage Range Of Battery System(V) |
540-788.4 |
| Capacity Of PCS(KW) |
500 |
| AC Output Voltage(V) |
400 |
| Recommened Working Range Of SOC |
5-100% |
| Cooling Mode |
Air Conditioning/Forced Cooling/Liquid Cooling |
| Protection Level |
IP 54 |
| Total Weight(Kg) |
20±0.5T |
| Dimension(mm) |
6096x2438x2891mm |
| Operating Temperature Range |
Charge:0~55℃ Dischagre:-20~60℃ |
| Note:Power and capacity can be expanded,customization is accepted,please contact wit our sales for further advice |
