| MODEL |
VP48200HV |
VP48280HV |
VP48300HV |
| Batteries materials |
Lithium iron phosphate |
| Series parallel mode(S series,P parallel) |
16SP2 |
| Rate voltage |
51.2V |
| Rate capacity |
200Ah |
280Ah |
300Ah |
| Size(mm) |
900*490*200 |
900*490*200 |
900*490*200 |
| Weight |
90kg |
110kg |
120kg |
| Color |
Optional |
| Parallel support |
Parallel terminals are supported |
| Output port mode |
terminal |
| Charging way |
CC/CV |
| Charging current |
0.2C(standard) |
| Maximum charging current |
Max0.5C@25℃ |
| Charge cut-off voltage |
58.4V |
| Discharge way |
CC/CP/VP |
| Discharge current |
1C |
| Maximum charge current |
Max1C@25℃ |
| Discharge cut-off current |
44.8V |
| Communication interface |
RS485/RS232/CAN |
| Charging operating temperature |
Charging:0~+50℃ |
| Discharge operating temperature |
Discharge:-20~+55℃ |
| The quality assurance period |
60 months |
